How To Pulverize the Diatomite Properly





   Diatomite ,also known as diatomaceous earth , is a naturally occurring soft . It is easily crumbled into a fine white to off-white powder. It has a particle size ranging from less than 3 micrometers to more than 1 millimeter, but typically 10 to 200 micrometers. Depending on the granularity, this powder can have an abrasive feel. It is very light because of its high porosity. Diatomite consists of fossilized remains of diatoms. It is used as a filtration aid, mild abrasive in products including toothpaste,


     Diatomite vertical mill  machine is professionally processing fine and superfine powder of non-inflammable, non-explosive and brittle materials with Moh's hardness under six, the moisture under 5% such as calcite, chalk, limestone, dolomite, kaolin, bentonite, talc, mica, magnesite, illite, pyrophyllite and vermiculite, sepiolite, attapulgite, rectorite, diatomite, barite, gypsum, alunite, graphite, fluorite, rock phosphate, Kalium ore, pumice, etc., totally more than 100 kinds of materials.
Finished diatomite powder fineness: 47-5 micron (325mesh-2500mesh)
Capacity: 0.4-12T per hour
Models diatomite vertical mill machine : HGM80/HGM90/HGM100/HGM100A/HGM125
Working principle:
1) After crushed by hammer crusher, the large materials become smaller pieces and are sent to the micro powder grinding mill.
2) When the micro powder grinding mill is at work, the granulated materials are crushed and grinded by the rollers into particles below 47micron.
3) The high-pressure air blower constantly inhales air within the micro powder grinding mill.
4) Along with the high speed airflow, micronized materials are brought to the classifier.
5) The qualified particles are screened and driven into the cyclone powder collector, finally exit from the discharging valve at the bottom;
6) A small proportion of the fine powders, with airflow, moving to the dust cleaner. Filtered clean air will be emitted from the air outlet of muffler in the end.


Technical data of  diatomite vertical mill machine
Model HGM80 HGM90 HGM100 HGM100A HGM125
Ring Diameter(mm) 800 900 1000 1000 1250
Ring Number/pcs 3 3-4 3-4 4 4
Roller Number/pcs 21 24-32 27-36 27-36 40-44
Main Shaft Speed/r. p. min 230-240 200-220 180-200 180-200 135-155
Input Size/mm ≦15
Finished Size/um 5-47(325-3000)
Capacity t/h 0.4-4.5 0.4-5.5 0.4-6.5 0.4-7.5 0.7-10
Outlet Size L*W*H/m 13.9*4*6.2 14.7*4.8*7.2 18*4.6*8.6 18*4.6*8.6 14*9*10.25
